Plasma cutting machine with different working gas can cut all kinds of oxygen to cut difficult to cut metal, especially for non-ferrous metals (stainless steel, carbon steel, aluminum, copper, titanium, nickel). The main advantage of the plasma cutter is that the cutting thickness is not when the metal is large, the plasma cutting speed is fast, especially when cutting ordinary carbon steel sheets, the speed can reach 5-6 times of the oxygen cutting method, the cutting surface is smooth, the thermal deformation is small, and there is almost no heat affected zone.
Plasma Cutting Machine Features:
1. The frame adopts all-welded structure, which is firm and reasonable, easy to operate and durable.
2. Cutting speed and high precision. The cutting mouth is small, neat and has no slag. On the basis of the traditional numerical control system, the control method for cutting is improved, and the secondary dressing processing is avoided.
3. Suitable for low carbon steel, copper, iron, aluminum, galvanized, titanium and other metal plates.
4. The plasma cutter CNC system configuration is high. Automatic arc ignition, stable performance, the success rate of arc ignition is more than 99%.
5. Support standard G code path files generated by software such as ARTCAM and Type3. The plasma cutting machine control system uses U disk to exchange processing files, which is convenient and quick to operate.
Models Available:
|
Model |
PLC-3000 |
PLC-4000 |
PLC-5000 |
PLC-6000 |
|
Width |
3000mm |
4000mm |
5000mm |
6000mm |
|
Effective cutting width |
2200mm |
3200mm |
4200mm |
5200mm |
|
Length |
12m Length infinitely extention |
|||
|
Effective cutting length |
12m Length infinitely extention |
|||
|
Plasma cutting speed |
500-3000mm/min |
|||
|
Back speed |
6000mm/min |
|||
|
Drive way |
Double drive |
|||
|
Plasma cutting thickness |
Depend on plasma source |
|||
|
Accuracy of repetition |
±0.01mm/m |
|||
|
Linear position accuracy |
±0.2mm/10m |
|||
|
Torch lift height |
170mm |
|||
|
Surface roughness |
Ra12.5 |
|||
|
Plasma cutting gas |
Dry, oil-free compressed air |
|||
|
File input |
USB interface |
|||
